Details

---

Performance features:
● Suitable for various copper and aluminum door and window profiles, industrial aluminum profiles, and various profile processing techniques;
● It adopts high-precision linear guides, roller screws, and servo motors to ensure smooth movement and high positioning and machining accuracy;
● Employing a servo spindle, it offers stable rotation, low noise, and strong cutting capability;
● It adopts a vegetable oil micro-cooling system, which effectively improves tool life and is non-toxic and pollution-free;
● It supports CNC G-code machining and CAD drawing import. It enables integrated drilling, milling, and tapping of profiles.
● The adoption of a CNC control system, with its intelligent system and simple, intuitive human-machine interface, makes operation more convenient and faster

Technical Specifications
水冷/风冷电机功率 Water/Air Cooled Motor Power	7.5kw / 9kw	主轴转速 Spindle Speed	18000r/min
X/Z/Y轴伺服电机 X/Z/Y Servo Motor	0.85kw×3	X轴行程 X-axis Travel	3000/6000mm
刀库伺服电机 Router Servo Motor	0.75kw	Y轴行程 Y-axis Travel	250mm
工作气压 Operating Voltage	0.6-0.8Mpa	Z轴行程 Z-axis Travel	250mm
工作电压 Working Pressure	380V	控制系统品牌 Operating Voltage	Taiwan Baoyuan/Jingke
重量 Weight	2800kg	自动换刀 Auto Tools Magazine	8 tool rotary magazine
外形尺寸 Overall Dimensions	4800 × 1580 ×2200mm
